## Introduction

Welcome to Lesson 2 of our deep learning series! In this lesson, we have an amazing PyTorch tutorial that will help you become a master of deep learning techniques. PyTorch is well-known for its flexibility, user-friendly interface, and impressive GPU acceleration.

**But don’t forget to check: **

- Lesson 1: Best Deep Learning Tutorial for Beginners 2024
- Lesson 2: Best Pytorch Tutorial for Deep Learning
- Lesson 3: Best Transformers and BERT Tutorial with Deep Learning and NLP
- Lesson 4: Best Deep Reinforcement Learning Course
- Lesson 5: Introduction to Deep Learning with a Simple LSTM

Throughout this tutorial, we will walk you through the essential steps of building and training neural networks using **PyTorch**. We will cover various topics such as working with **matrices**, implementing **neural network models**, and harnessing the power of **dynamic computation graphs**.

So, let’s jump right in and take your deep learning journey to new heights with PyTorch!

pytorch

pytorch install

install pytorch

installing pytorch

pytorch lightning

pytorch-lightning

## What is PyTorch?

PyTorch is a Python-based scientific computing package designed for two main purposes:

**GPU-Accelerated NumPy Replacement**: Harness the power of GPUs for numerical computations.**Deep Learning Research**: Offers maximum flexibility and speed for developing deep learning models.

**Advantages**

**Interactive Debugging**: Easier to debug and visualize compared to many other frameworks.**Dynamic Graphs**: Excellent support for dynamic computational graphs.**Facebook Support**: Backed by a robust organization.**Flexible APIs**: Combines high-level and low-level APIs for versatile use.

pytorch dataloader

pytorch data loader

install torch

pytorch tutorial

pytorch vs tensorflow

**Disadvantages**

**Maturity**: Not as mature as some alternative frameworks.**Resources**: Limited references and resources beyond official documentation.

## Note

This guide assumes you are familiar with the basics of neural networks. If not, please refer to my beginner’s tutorial. The tutorial provides foundational knowledge crucial for understanding and using PyTorch for neural networks.

## How to install Pytorch

**To install PyTorch, you can easily follow these steps:**

**Choose your Installation Options**: PyTorch provides different installation options based on your system configuration, including your operating system, Python version, CUDA support (for GPU acceleration), and package manager preference (pip or conda).**Visit the PyTorch Website**: Simply go to the official PyTorch website at pytorch.org.**Select Installation Options**: On the PyTorch website, head to the “Get Started” section or click on the “Quick Start” button. There, you’ll find options to select your desired installation configurations.**Generate Installation Command**: Once you’ve made your selections, the website will generate an installation command specifically tailored to your preferences. Just copy this command.**Open Terminal or Command Prompt**: Open the terminal or command prompt on your system.**Paste and Execute Installation Command**: Paste the copied installation command into your terminal or command prompt, and hit Enter to execute it. This command will download and install PyTorch, along with its dependencies, based on your chosen configurations.**Verify Installation**: After the installation is complete, you can verify that PyTorch has been installed correctly by opening a Python interpreter and importing the PyTorch library:

` import torch`

**If there are no errors, it means PyTorch has been successfully installed.**

**Additional Steps (Optional)**: Depending on your specific requirements or system configuration, you may need to perform additional steps, such as setting up CUDA for GPU support or configuring virtual environments.

By following these steps, you’ll be able to install PyTorch on your system and start using it for deep learning tasks.

If you encounter any issues during the installation process, referring to the official PyTorch documentation or seeking assistance from online communities can be really helpful.

## Is PyTorch better than TensorFlow?

There are several factors to consider when deciding whether PyTorch is superior to TensorFlow. These factors include your specific use case, personal preferences, and requirements.

PyTorch and TensorFlow are both robust deep learning frameworks that are extensively utilized in the machine learning community.** Each framework has its own unique strengths and benefits.**

Feature | PyTorch | TensorFlow |
---|---|---|

Computational Graph | Dynamic (eager execution by default) | Originally static (with TensorFlow 2.0 introducing eager execution) |

Interface | More pythonic, easier to write and debug | Not as pythonic, but improving with TensorFlow 2.0 |

Community Support | Rapidly growing, vibrant community | Large and established community |

Documentation | Extensive and well-maintained | Extensive and well-maintained |

Ecosystem | Growing ecosystem with rich libraries and tools | Mature ecosystem with extensive pre-trained models and tools |

Deployment | Suitable for research and development | Strong support for large-scale and production-level deployments |

Distributed Computing | Less mature support for distributed computing | Strong support for distributed computing and deployment on various platforms |

Mobile and Edge Deployment | Support available but less emphasis | Strong support for deployment on mobile and edge devices |

Industry Adoption | Increasing adoption in research and industry | Widely adopted in industry and academia |

Learning Curve | Generally considered easier to learn | May have a steeper learning curve, especially for beginners |

## Is PyTorch written in C or C++?

PyTorch is mainly coded in C++. Although the essential features and computational backends of PyTorch are developed in C++, PyTorch also offers Python bindings to make it easier to use and integrate with the Python programming language.

This unique blend of C++ implementation for high performance and Python interface for user-friendliness makes PyTorch an incredibly robust and adaptable deep learning framework.

## Is PyTorch same as Python?

No, PyTorch and Python are not the same. PyTorch is a deep learning framework that is primarily written in C++, but it has Python bindings which enable users to use PyTorch with Python.

Python is a high-level programming language that is famous for its simplicity and readability, whereas PyTorch is a library or framework that is built using a combination of Python and other languages like C++ for its core functionality.

**To summarize, PyTorch is a tool that is used within the Python programming environment to make deep learning tasks easier, but it is not equivalent to Python itself.**

## Let’s Start Deep Learning Code

# This Python 3 environment comes with many helpful analytics libraries installed # It is defined by the kaggle/python docker image: https://github.com/kaggle/docker-python # For example, here's several helpful packages to load in import numpy as np # linear algebra import pandas as pd # data processing, CSV file I/O (e.g. pd.read_csv) import matplotlib.pyplot as plt # Input data files are available in the "../input/" directory. # For example, running this (by clicking run or pressing Shift+Enter) will list the files in the input directory import os print(os.listdir("../input")) # Any results you write to the current directory are saved as output.

['train.csv', 'test.csv', 'sample_submission.csv']

pytorch github

tensorflow vs pytorch

what is pytorch

conda install pytorch

nn conv2d

pytorch geometric

data loader pytorch

dataloader pytorch

## Basics of Pytorch

### Matrices

Tensors in PyTorch are essentially matrices or arrays. So, a 3×3 matrix is called a 3×3 tensor in PyTorch.

Now, let’s take a look at how we can work with arrays using NumPy, which I’m sure you’re already familiar with.

To create a NumPy array, we use the `np.array()`

method.

**There are a couple of useful functions we can use with arrays:**

- The
`type()`

function helps us determine the type of the array. In this case, it will be a NumPy array. - The
`np.shape()`

function returns the shape of the array, which is represented as rows x columns.

# import numpy library import numpy as np # numpy array array = [[1,2,3],[4,5,6]] first_array = np.array(array) # 2x3 array print("Array Type: {}".format(type(first_array))) # type print("Array Shape: {}".format(np.shape(first_array))) # shape print(first_array)

Array Type: <class 'numpy.ndarray'> Array Shape: (2, 3) [[1 2 3] [4 5 6]]

We’ve looked at NumPy arrays. Now, let’s see how to implement tensors (PyTorch arrays).

First, import the PyTorch library with `import torch`

.

**We create a tensor using the torch.Tensor() method.**

`type()`

: Determines the type of the array. In this example, it will be a tensor.`shape`

: Returns the shape of the array in the form of rows x columns.

# import pytorch library import torch # pytorch array tensor = torch.Tensor(array) print("Array Type: {}".format(tensor.type)) # type print("Array Shape: {}".format(tensor.shape)) # shape print(tensor)

Array Type: <built-in method type of Tensor object at 0x7fde8c4685a0> Array Shape: torch.Size([2, 3]) tensor([[1., 2., 3.], [4., 5., 6.]])

Allocation is a fundamental technique in coding. Let’s learn how to do it with PyTorch by comparing it to NumPy.

**Here’s how similar operations are performed in both libraries:**

`np.ones()`

in NumPy is equivalent to`torch.ones()`

in PyTorch.`np.random.rand()`

in NumPy is equivalent to`torch.rand()`

in PyTorch.

# numpy ones print("Numpy {}\n".format(np.ones((2,3)))) # pytorch ones print(torch.ones((2,3)))

Numpy [[1. 1. 1.] [1. 1. 1.]] tensor([[1., 1., 1.], [1., 1., 1.]])

# numpy random print("Numpy {}\n".format(np.random.rand(2,3))) # pytorch random print(torch.rand(2,3))

Numpy [[0.9917393 0.10286286 0.61706085] [0.03963639 0.01170117 0.35111965]] tensor([[0.1462, 0.7302, 0.8815], [0.5960, 0.1152, 0.6170]])

Even when using PyTorch for neural networks, I often prefer using NumPy for visualization and examination. Therefore, I usually convert the tensor results from the neural network to NumPy arrays.

pip install pytorch

pip install torch

conv2d

pytorch lstm

pytorch dataset

pytorch datasets

pytorch database

pytorch conv2d

**Here’s how to convert between tensors and NumPy arrays:**

`torch.from_numpy()`

: Converts a NumPy array to a tensor.`tensor.numpy()`

: Converts a tensor to a NumPy array.

# random numpy array array = np.random.rand(2,2) print("{} {}\n".format(type(array),array)) # from numpy to tensor from_numpy_to_tensor = torch.from_numpy(array) print("{}\n".format(from_numpy_to_tensor)) # from tensor to numpy tensor = from_numpy_to_tensor from_tensor_to_numpy = tensor.numpy() print("{} {}\n".format(type(from_tensor_to_numpy),from_tensor_to_numpy))

<class 'numpy.ndarray'> [[0.27035945 0.97245412]

[0.63432523 0.94168862]]

tensor([[0.2704, 0.9725],

[0.6343, 0.9417]], dtype=torch.float64)

<class 'numpy.ndarray'> [[0.27035945 0.97245412]

[0.63432523 0.94168862]]

### Basic Math with PyTorch

**Resize**:`view()`

**Given a and b as tensors:**

**Addition**:`torch.add(a, b)`

or`a + b`

**Subtraction**:`a.sub(b)`

or`a - b`

**Element-wise Multiplication**:`torch.mul(a, b)`

or`a * b`

**Element-wise Division**:`torch.div(a, b)`

or`a / b`

**Mean**:`a.mean()`

**Standard Deviation (std)**:`a.std()`

# create tensor tensor = torch.ones(3,3) print("\n",tensor) # Resize print("{}{}\n".format(tensor.view(9).shape,tensor.view(9))) # Addition print("Addition: {}\n".format(torch.add(tensor,tensor))) # Subtraction print("Subtraction: {}\n".format(tensor.sub(tensor))) # Element wise multiplication print("Element wise multiplication: {}\n".format(torch.mul(tensor,tensor))) # Element wise division print("Element wise division: {}\n".format(torch.div(tensor,tensor))) # Mean tensor = torch.Tensor([1,2,3,4,5]) print("Mean: {}".format(tensor.mean())) # Standart deviation (std) print("std: {}".format(tensor.std()))

tensor([[1., 1., 1.], [1., 1., 1.], [1., 1., 1.]]) torch.Size([9])tensor([1., 1., 1., 1., 1., 1., 1., 1., 1.]) Addition: tensor([[2., 2., 2.], [2., 2., 2.], [2., 2., 2.]]) Subtraction: tensor([[0., 0., 0.], [0., 0., 0.], [0., 0., 0.]]) Element wise multiplication: tensor([[1., 1., 1.], [1., 1., 1.], [1., 1., 1.]]) Element wise division: tensor([[1., 1., 1.], [1., 1., 1.], [1., 1., 1.]]) Mean: 3.0 std: 1.5811388492584229

### Variables

Variables in PyTorch accumulate gradients.

In neural networks, especially during backpropagation, gradients are crucially calculated. Therefore, handling gradients becomes essential.

If you’re unfamiliar with neural networks, I recommend checking out my deep learning tutorial first, as I won’t delve into detailed concepts such as optimization, loss functions, or backpropagation here: Deep learning tutorial.

The key difference between variables and tensors is that variables accumulate gradients.

Variables also support mathematical operations. They are indispensable for performing backward propagation in neural networks.

# import variable from pytorch library from torch.autograd import Variable # define variable var = Variable(torch.ones(3), requires_grad = True) var

tensor([1., 1., 1.], requires_grad=True)

Let’s consider the equation ( y = x^2 ).

Define ( x = [2,4] ) as a variable.

After calculation, we find ( y = [4,16] ) (( y = x^2 )).

Recapping the equation, ( o = \frac{1}{2}\sum(y) = \frac{1}{2}\sum(x^2) ).

pytorch cuda

pytorch-cuda

torch utils data dataloader

torch python

pytorch version

pytorch versions

pytorch download

The derivative of ( o = x ).

Resultantly, gradients are equal to ( x ), thus ( \text{gradients} = [2,4] ).

Let’s implement this.

# lets make basic backward propagation # we have an equation that is y = x^2 array = [2,4] tensor = torch.Tensor(array) x = Variable(tensor, requires_grad = True) y = x**2 print(" y = ",y) # recap o equation o = 1/2*sum(y) o = (1/2)*sum(y) print(" o = ",o) # backward o.backward() # calculates gradients # As I defined, variables accumulates gradients. In this part there is only one variable x. # Therefore variable x should be have gradients # Lets look at gradients with x.grad print("gradients: ",x.grad)

y = tensor([ 4., 16.], grad_fn=<PowBackward0>)

o = tensor(10., grad_fn=<MulBackward0>)

gradients: tensor([2., 4.])

### Linear Regression

For a detailed explanation of linear regression, refer to the “Regression” section of my machine learning tutorial: Machine Learning Tutorial

**In linear regression, we have the equation ( y = Ax + B ):**

- ( A ) represents the slope of the curve.
- ( B ) represents the bias, the point where the curve intersects the y-axis.

For example, consider a car company. If the car price is low, we sell more cars. Conversely, if the car price is high, we sell fewer cars. This is a known fact, and we have a dataset that reflects this relationship.

The question arises: What will be the number of cars sold if the car price is $100?

# As a car company we collect this data from previous selling # lets define car prices car_prices_array = [3,4,5,6,7,8,9] car_price_np = np.array(car_prices_array,dtype=np.float32) car_price_np = car_price_np.reshape(-1,1) car_price_tensor = Variable(torch.from_numpy(car_price_np)) # lets define number of car sell number_of_car_sell_array = [ 7.5, 7, 6.5, 6.0, 5.5, 5.0, 4.5] number_of_car_sell_np = np.array(number_of_car_sell_array,dtype=np.float32) number_of_car_sell_np = number_of_car_sell_np.reshape(-1,1) number_of_car_sell_tensor = Variable(torch.from_numpy(number_of_car_sell_np)) # lets visualize our data import matplotlib.pyplot as plt plt.scatter(car_prices_array,number_of_car_sell_array) plt.xlabel("Car Price $") plt.ylabel("Number of Car Sell") plt.title("Car Price$ VS Number of Car Sell") plt.show()

how to install pytorch

conv2d pytorch

pytorch optimizers

pytorch optimizer

pytorch optimization

lstm pytorch

pytorch profiler

pytorch profiling

### Analyzing Collected Data

The plot before us represents our collected data.

Our primary inquiry: What will be the number of cars sold if the car price is $100?

To address this question, we’ll employ linear regression. The objective is to fit a line to this data with minimal error.

**Steps of Linear Regression:**

- Instantiate the LinearRegression class.
- Define the model using this LinearRegression class.
- Calculate the Mean Squared Error (MSE).
- Optimize the model using Stochastic Gradient Descent (SGD).
- Conduct Backpropagation.
- Make Predictions.

Let’s proceed to implement this using PyTorch.

# Linear Regression with Pytorch # libraries import torch from torch.autograd import Variable import torch.nn as nn import warnings warnings.filterwarnings("ignore") # create class class LinearRegression(nn.Module): def __init__(self,input_size,output_size): # super function. It inherits from nn.Module and we can access everythink in nn.Module super(LinearRegression,self).__init__() # Linear function. self.linear = nn.Linear(input_dim,output_dim) def forward(self,x): return self.linear(x) # define model input_dim = 1 output_dim = 1 model = LinearRegression(input_dim,output_dim) # input and output size are 1 # MSE mse = nn.MSELoss() # Optimization (find parameters that minimize error) learning_rate = 0.02 # how fast we reach best parameters optimizer = torch.optim.SGD(model.parameters(),lr = learning_rate) # train model loss_list = [] iteration_number = 1001 for iteration in range(iteration_number): # optimization optimizer.zero_grad() # Forward to get output results = model(car_price_tensor) # Calculate Loss loss = mse(results, number_of_car_sell_tensor) # backward propagation loss.backward() # Updating parameters optimizer.step() # store loss loss_list.append(loss.data) # print loss if(iteration % 50 == 0): print('epoch {}, loss {}'.format(iteration, loss.data)) plt.plot(range(iteration_number),loss_list) plt.xlabel("Number of Iterations") plt.ylabel("Loss") plt.show()

epoch 0, loss 13.964462280273438 epoch 50, loss 4.808793544769287 epoch 100, loss 3.2495040893554688 epoch 150, loss 2.195826768875122 epoch 200, loss 1.4838119745254517 epoch 250, loss 1.0026743412017822 epoch 300, loss 0.6775489449501038 epoch 350, loss 0.4578486979007721 epoch 400, loss 0.30938759446144104 epoch 450, loss 0.20906630158424377 epoch 500, loss 0.14127501845359802 epoch 550, loss 0.09546550363302231 epoch 600, loss 0.06451006978750229 epoch 650, loss 0.043592456728219986 epoch 700, loss 0.029456866905093193 epoch 750, loss 0.019905563443899155 epoch 800, loss 0.013450978323817253 epoch 850, loss 0.009089605882763863 epoch 900, loss 0.006142175756394863 epoch 950, loss 0.004150448366999626 epoch 1000, loss 0.0028045533690601587

After 1001 iterations, the loss is nearly zero, as evident from the plot or the loss recorded at epoch 1000. With this, we now possess a trained model.

Using this trained model, let’s proceed to predict car prices.

# predict our car price predicted = model(car_price_tensor).data.numpy() plt.scatter(car_prices_array,number_of_car_sell_array,label = "original data",color ="red") plt.scatter(car_prices_array,predicted,label = "predicted data",color ="blue") # predict if car price is 10$, what will be the number of car sell #predicted_10 = model(torch.from_numpy(np.array([10]))).data.numpy() #plt.scatter(10,predicted_10.data,label = "car price 10$",color ="green") plt.legend() plt.xlabel("Car Price $") plt.ylabel("Number of Car Sell") plt.title("Original vs Predicted values") plt.show()

### Logistic Regression

Linear regression isn’t suitable for classification tasks, leading us to logistic regression.

By combining linear regression with the logistic function (softmax), we derive logistic regression.

**Steps of Logistic Regression:**

Step | Description |
---|---|

1. Import Libraries | Import necessary libraries. |

2. Prepare Dataset | – Use the MNIST dataset. – Normalize data. – Split into training and testing sets. |

3. Create Feature and Target Tensors | Define batch size and epoch for training. |

4. TensorDataset() and DataLoader() | Prepare data for training and testing. |

5. Visualize Dataset | View one of the images in the dataset. |

6. Create Logistic Regression Model | Build a model similar to linear regression but with a logistic function in the loss function. |

7. Instantiate Model | Define input and output dimensions. |

8. Instantiate Loss | Use cross-entropy loss with softmax. |

9. Instantiate Optimizer | Choose Stochastic Gradient Descent (SGD) optimizer. |

10. Train the Model | Observe the loss decreasing and accuracy increasing during training. |

11. Prediction | Visualize the learning progress through loss and accuracy plots. |

# Import Libraries import torch import torch.nn as nn from torch.autograd import Variable from torch.utils.data import DataLoader import pandas as pd from sklearn.model_selection import train_test_split

# Prepare Dataset # load data train = pd.read_csv(r"../input/train.csv",dtype = np.float32) # split data into features(pixels) and labels(numbers from 0 to 9) targets_numpy = train.label.values features_numpy = train.loc[:,train.columns != "label"].values/255 # normalization # train test split. Size of train data is 80% and size of test data is 20%. features_train, features_test, targets_train, targets_test = train_test_split(features_numpy, targets_numpy, test_size = 0.2, random_state = 42) # create feature and targets tensor for train set. As you remember we need variable to accumulate gradients. Therefore first we create tensor, then we will create variable featuresTrain = torch.from_numpy(features_train) targetsTrain = torch.from_numpy(targets_train).type(torch.LongTensor) # data type is long # create feature and targets tensor for test set. featuresTest = torch.from_numpy(features_test) targetsTest = torch.from_numpy(targets_test).type(torch.LongTensor) # data type is long # batch_size, epoch and iteration batch_size = 100 n_iters = 10000 num_epochs = n_iters / (len(features_train) / batch_size) num_epochs = int(num_epochs) # Pytorch train and test sets train = torch.utils.data.TensorDataset(featuresTrain,targetsTrain) test = torch.utils.data.TensorDataset(featuresTest,targetsTest) # data loader train_loader = DataLoader(train, batch_size = batch_size, shuffle = False) test_loader = DataLoader(test, batch_size = batch_size, shuffle = False) # visualize one of the images in data set plt.imshow(features_numpy[10].reshape(28,28)) plt.axis("off") plt.title(str(targets_numpy[10])) plt.savefig('graph.png') plt.show()

# Create Logistic Regression Model class LogisticRegressionModel(nn.Module): def __init__(self, input_dim, output_dim): super(LogisticRegressionModel, self).__init__() # Linear part self.linear = nn.Linear(input_dim, output_dim) # There should be logistic function right? # However logistic function in pytorch is in loss function # So actually we do not forget to put it, it is only at next parts def forward(self, x): out = self.linear(x) return out # Instantiate Model Class input_dim = 28*28 # size of image px*px output_dim = 10 # labels 0,1,2,3,4,5,6,7,8,9 # create logistic regression model model = LogisticRegressionModel(input_dim, output_dim) # Cross Entropy Loss error = nn.CrossEntropyLoss() # SGD Optimizer learning_rate = 0.001 optimizer = torch.optim.SGD(model.parameters(), lr=learning_rate)

# Traning the Model count = 0 loss_list = [] iteration_list = [] for epoch in range(num_epochs): for i, (images, labels) in enumerate(train_loader): # Define variables train = Variable(images.view(-1, 28*28)) labels = Variable(labels) # Clear gradients optimizer.zero_grad() # Forward propagation outputs = model(train) # Calculate softmax and cross entropy loss loss = error(outputs, labels) # Calculate gradients loss.backward() # Update parameters optimizer.step() count += 1 # Prediction if count % 50 == 0: # Calculate Accuracy correct = 0 total = 0 # Predict test dataset for images, labels in test_loader: test = Variable(images.view(-1, 28*28)) # Forward propagation outputs = model(test) # Get predictions from the maximum value predicted = torch.max(outputs.data, 1)[1] # Total number of labels total += len(labels) # Total correct predictions correct += (predicted == labels).sum() accuracy = 100 * correct / float(total) # store loss and iteration loss_list.append(loss.data) iteration_list.append(count) if count % 500 == 0: # Print Loss print('Iteration: {} Loss: {} Accuracy: {}%'.format(count, loss.data, accuracy))

Iteration: 500 Loss: 1.8399910926818848 Accuracy: 68% Iteration: 1000 Loss: 1.5982391834259033 Accuracy: 75% Iteration: 1500 Loss: 1.2930790185928345 Accuracy: 78% Iteration: 2000 Loss: 1.1937870979309082 Accuracy: 80% Iteration: 2500 Loss: 1.0323244333267212 Accuracy: 81% Iteration: 3000 Loss: 0.9379988312721252 Accuracy: 82% Iteration: 3500 Loss: 0.899523913860321 Accuracy: 82% Iteration: 4000 Loss: 0.7464531660079956 Accuracy: 83% Iteration: 4500 Loss: 0.9766625761985779 Accuracy: 83% Iteration: 5000 Loss: 0.8022621870040894 Accuracy: 83% Iteration: 5500 Loss: 0.7587511539459229 Accuracy: 84% Iteration: 6000 Loss: 0.8655218482017517 Accuracy: 84% Iteration: 6500 Loss: 0.6625986695289612 Accuracy: 84% Iteration: 7000 Loss: 0.7128363251686096 Accuracy: 84% Iteration: 7500 Loss: 0.6303086280822754 Accuracy: 85% Iteration: 8000 Loss: 0.7414441704750061 Accuracy: 85% Iteration: 8500 Loss: 0.5468852519989014 Accuracy: 85% Iteration: 9000 Loss: 0.6567560434341431 Accuracy: 85% Iteration: 9500 Loss: 0.5228758454322815 Accuracy: 85%

# visualization plt.plot(iteration_list,loss_list) plt.xlabel("Number of iteration") plt.ylabel("Loss") plt.title("Logistic Regression: Loss vs Number of iteration") plt.show()

### Artificial Neural Network (ANN)

While logistic regression performs well for classification, its accuracy tends to decrease as complexity (non-linearity) increases. To address this, we enhance the model’s complexity by incorporating more non-linear functions through hidden layers.

For a comprehensive understanding of artificial neural networks (ANN), please refer to my deep learning tutorial: Deep learning tutorial

#### Steps of ANN:

Step | Description |
---|---|

1. Import Libraries | Import necessary libraries. |

2. Prepare Dataset | – Use the same dataset as logistic regression. – Prepare train_loader and test_loader. – Keep batch size, epoch, and iteration numbers the same. |

3. Create ANN Model | – Add 3 hidden layers. – Use ReLU, Tanh, and ELU activation functions for diversity. |

4. Instantiate Model Class | – Input dimension: 28×28 (image size in pixels). – Output dimension: 10 (labels 0 to 9). – Hidden layer dimension: 150 (hyperparameter). |

5. Instantiate Loss | Cross-entropy loss with softmax (logistic function). |

6. Instantiate Optimizer | Stochastic Gradient Descent (SGD) optimizer. |

7. Train the Model | Observe decreasing loss and increasing accuracy during training. |

8. Prediction | Visualize the learning progress through loss and accuracy plots. |

Through the incorporation of hidden layers, the model learns better, achieving a higher accuracy (almost 95%) compared to the logistic regression model.

# Import Libraries import torch import torch.nn as nn from torch.autograd import Variable

# Create ANN Model class ANNModel(nn.Module): def __init__(self, input_dim, hidden_dim, output_dim): super(ANNModel, self).__init__() # Linear function 1: 784 --> 150 self.fc1 = nn.Linear(input_dim, hidden_dim) # Non-linearity 1 self.relu1 = nn.ReLU() # Linear function 2: 150 --> 150 self.fc2 = nn.Linear(hidden_dim, hidden_dim) # Non-linearity 2 self.tanh2 = nn.Tanh() # Linear function 3: 150 --> 150 self.fc3 = nn.Linear(hidden_dim, hidden_dim) # Non-linearity 3 self.elu3 = nn.ELU() # Linear function 4 (readout): 150 --> 10 self.fc4 = nn.Linear(hidden_dim, output_dim) def forward(self, x): # Linear function 1 out = self.fc1(x) # Non-linearity 1 out = self.relu1(out) # Linear function 2 out = self.fc2(out) # Non-linearity 2 out = self.tanh2(out) # Linear function 2 out = self.fc3(out) # Non-linearity 2 out = self.elu3(out) # Linear function 4 (readout) out = self.fc4(out) return out # instantiate ANN input_dim = 28*28 hidden_dim = 150 #hidden layer dim is one of the hyper parameter and it should be chosen and tuned. For now I only say 150 there is no reason. output_dim = 10 # Create ANN model = ANNModel(input_dim, hidden_dim, output_dim) # Cross Entropy Loss error = nn.CrossEntropyLoss() # SGD Optimizer learning_rate = 0.02 optimizer = torch.optim.SGD(model.parameters(), lr=learning_rate)

# ANN model training count = 0 loss_list = [] iteration_list = [] accuracy_list = [] for epoch in range(num_epochs): for i, (images, labels) in enumerate(train_loader): train = Variable(images.view(-1, 28*28)) labels = Variable(labels) # Clear gradients optimizer.zero_grad() # Forward propagation outputs = model(train) # Calculate softmax and ross entropy loss loss = error(outputs, labels) # Calculating gradients loss.backward() # Update parameters optimizer.step() count += 1 if count % 50 == 0: # Calculate Accuracy correct = 0 total = 0 # Predict test dataset for images, labels in test_loader: test = Variable(images.view(-1, 28*28)) # Forward propagation outputs = model(test) # Get predictions from the maximum value predicted = torch.max(outputs.data, 1)[1] # Total number of labels total += len(labels) # Total correct predictions correct += (predicted == labels).sum() accuracy = 100 * correct / float(total) # store loss and iteration loss_list.append(loss.data) iteration_list.append(count) accuracy_list.append(accuracy) if count % 500 == 0: # Print Loss print('Iteration: {} Loss: {} Accuracy: {} %'.format(count, loss.data, accuracy))

Iteration: 500 Loss: 0.8311067223548889 Accuracy: 77 % Iteration: 1000 Loss: 0.4767582416534424 Accuracy: 87 % Iteration: 1500 Loss: 0.21807175874710083 Accuracy: 89 % Iteration: 2000 Loss: 0.2915269732475281 Accuracy: 90 % Iteration: 2500 Loss: 0.3073478937149048 Accuracy: 91 % Iteration: 3000 Loss: 0.12328791618347168 Accuracy: 92 % Iteration: 3500 Loss: 0.24098418653011322 Accuracy: 93 % Iteration: 4000 Loss: 0.06471655517816544 Accuracy: 93 % Iteration: 4500 Loss: 0.3368555009365082 Accuracy: 94 % Iteration: 5000 Loss: 0.12026549130678177 Accuracy: 94 % Iteration: 5500 Loss: 0.217212975025177 Accuracy: 94 % Iteration: 6000 Loss: 0.20914879441261292 Accuracy: 94 % Iteration: 6500 Loss: 0.10008767992258072 Accuracy: 95 % Iteration: 7000 Loss: 0.13490895926952362 Accuracy: 95 % Iteration: 7500 Loss: 0.11741413176059723 Accuracy: 95 % Iteration: 8000 Loss: 0.17519493401050568 Accuracy: 95 % Iteration: 8500 Loss: 0.06657659262418747 Accuracy: 95 % Iteration: 9000 Loss: 0.05512683466076851 Accuracy: 95 % Iteration: 9500 Loss: 0.02535334974527359 Accuracy: 96 %

# visualization loss plt.plot(iteration_list,loss_list) plt.xlabel("Number of iteration") plt.ylabel("Loss") plt.title("ANN: Loss vs Number of iteration") plt.show() # visualization accuracy plt.plot(iteration_list,accuracy_list,color = "red") plt.xlabel("Number of iteration") plt.ylabel("Accuracy") plt.title("ANN: Accuracy vs Number of iteration") plt.show()

### Convolutional Neural Network (CNN)

CNNs are well-suited for image classification tasks.

#### Steps of CNN:

Step | Description |
---|---|

1. Import Libraries | Import necessary libraries. |

2. Prepare Dataset | – Use the same dataset as previous parts. – Prepare train_loader and test_loader. |

3. Convolutional Layer | – Create feature maps with filters (kernels). – Apply padding to preserve information. |

4. Pooling Layer | – Condense feature maps from convolutional layer. – Utilize max pooling. |

5. Flattening | Flatten the feature maps. |

6. Fully Connected Layer | – Similar to ANN or linear regression. – Apply softmax function at the end. |

7. Instantiate Model Class | Define the CNN model. |

8. Instantiate Loss | Cross-entropy loss with softmax function. |

9. Instantiate Optimizer | Stochastic Gradient Descent (SGD) optimizer. |

10. Train the Model | Observe decreasing loss and increasing accuracy during training. |

11. Prediction | Visualize learning progress through loss and accuracy plots. |

Through the integration of convolutional layers, the model learns more effectively, resulting in higher accuracy (almost 98%) compared to the ANN model.

While tuning hyperparameters such as increasing iterations and expanding the CNN can further enhance accuracy, it may also increase running time significantly.

# Import Libraries import torch import torch.nn as nn from torch.autograd import Variable

# Create CNN Model class CNNModel(nn.Module): def __init__(self): super(CNNModel, self).__init__() # Convolution 1 self.cnn1 = nn.Conv2d(in_channels=1, out_channels=16, kernel_size=5, stride=1, padding=0) self.relu1 = nn.ReLU() # Max pool 1 self.maxpool1 = nn.MaxPool2d(kernel_size=2) # Convolution 2 self.cnn2 = nn.Conv2d(in_channels=16, out_channels=32, kernel_size=5, stride=1, padding=0) self.relu2 = nn.ReLU() # Max pool 2 self.maxpool2 = nn.MaxPool2d(kernel_size=2) # Fully connected 1 self.fc1 = nn.Linear(32 * 4 * 4, 10) def forward(self, x): # Convolution 1 out = self.cnn1(x) out = self.relu1(out) # Max pool 1 out = self.maxpool1(out) # Convolution 2 out = self.cnn2(out) out = self.relu2(out) # Max pool 2 out = self.maxpool2(out) # flatten out = out.view(out.size(0), -1) # Linear function (readout) out = self.fc1(out) return out # batch_size, epoch and iteration batch_size = 100 n_iters = 2500 num_epochs = n_iters / (len(features_train) / batch_size) num_epochs = int(num_epochs) # Pytorch train and test sets train = torch.utils.data.TensorDataset(featuresTrain,targetsTrain) test = torch.utils.data.TensorDataset(featuresTest,targetsTest) # data loader train_loader = torch.utils.data.DataLoader(train, batch_size = batch_size, shuffle = False) test_loader = torch.utils.data.DataLoader(test, batch_size = batch_size, shuffle = False) # Create CNN model = CNNModel() # Cross Entropy Loss error = nn.CrossEntropyLoss() # SGD Optimizer learning_rate = 0.1 optimizer = torch.optim.SGD(model.parameters(), lr=learning_rate)

# CNN model training count = 0 loss_list = [] iteration_list = [] accuracy_list = [] for epoch in range(num_epochs): for i, (images, labels) in enumerate(train_loader): train = Variable(images.view(100,1,28,28)) labels = Variable(labels) # Clear gradients optimizer.zero_grad() # Forward propagation outputs = model(train) # Calculate softmax and ross entropy loss loss = error(outputs, labels) # Calculating gradients loss.backward() # Update parameters optimizer.step() count += 1 if count % 50 == 0: # Calculate Accuracy correct = 0 total = 0 # Iterate through test dataset for images, labels in test_loader: test = Variable(images.view(100,1,28,28)) # Forward propagation outputs = model(test) # Get predictions from the maximum value predicted = torch.max(outputs.data, 1)[1] # Total number of labels total += len(labels) correct += (predicted == labels).sum() accuracy = 100 * correct / float(total) # store loss and iteration loss_list.append(loss.data) iteration_list.append(count) accuracy_list.append(accuracy) if count % 500 == 0: # Print Loss print('Iteration: {} Loss: {} Accuracy: {} %'.format(count, loss.data, accuracy))

Iteration: 500 Loss: 0.11975778639316559 Accuracy: 96 % Iteration: 1000 Loss: 0.04979655146598816 Accuracy: 97 % Iteration: 1500 Loss: 0.03124646656215191 Accuracy: 97 % Iteration: 2000 Loss: 0.013534960336983204 Accuracy: 98 %

# visualization loss plt.plot(iteration_list,loss_list) plt.xlabel("Number of iteration") plt.ylabel("Loss") plt.title("CNN: Loss vs Number of iteration") plt.show() # visualization accuracy plt.plot(iteration_list,accuracy_list,color = "red") plt.xlabel("Number of iteration") plt.ylabel("Accuracy") plt.title("CNN: Accuracy vs Number of iteration") plt.show()

### Conclusion

Version 1: Your Exciting Deep Learning Adventure

This series of tutorials has walked you through the fundamental concepts of deep learning, building on the knowledge gained in Lesson 1: Top Deep Learning Tutorial for Beginners 2024. Now, in Lesson 2, we have delved into the intricacies of PyTorch.

To ensure a strong grasp of the material, I suggest reviewing Lesson 1 again before diving into PyTorch.

deep learning projects github

deep learning project github

deep learning project ideas

deep learning projects ideas

We have discussed topics such as linear and logistic regression, artificial neural networks (ANNs), convolutional neural networks (CNNs), recurrent neural networks (RNNs), and Long-Short Term Memory (LSTM) networks.

Continue your exploration and don’t hesitate to contact us with any inquiries or feedback. Your journey into the world of deep learning is just getting started!

## 2 Comments

## Best Deep Learning Tutorial For Beginners With Python 2024 · May 29, 2024 at 1:17 pm

[…] Lesson 2: Best Pytorch Tutorial for Deep Learning […]

## Lesson 3: Best Transformers And BERT Tutorial With DL/NLP · May 29, 2024 at 2:21 pm

[…] Lesson 2: Best Pytorch Tutorial for Deep Learning […]
